990FXA-GD80V2

Overview

featurePic

Lossless 24-bit/192KHz HD Audio

Onboard PC audio gets better! MSI is the first to implement the most high-end HD Audio codecs available. Don’t be fooled by other inferior audio solutions onboard (sometimes you can’t even find the driver!) Only MSI offers the Loss-less 24-bit/192KHz HD Audio function with an incredible 109 SNR dB value to provide the most clear & vivid HD audio quality and support 7.1 channels surround sound playback with a 2-channel independent stereo output (multiple streaming) through the front panel 3.5 inch phone jack.




featurePic

Winki 3

Winki 3 is a free Linux-based O/S which is based on the Linux core. With an ultra-fast  booting speed and a multi-language interface, the built-in Winki 3 provides an easy-to-use internet environment that includes the most popular functions such as internet surfing, web mail, instant messaging, picture browsing, and more. It's the most practical way to be online in the shortest time.

Features
- User friendly & totally free applications
- Power on to run applications in 25 seconds
- Multi-language interface support

featurePic

OC Genie II – Overclock & Unlock CPU Core in 1 Second

OC Genie II, the most powerful and easy overclocking technology is implemented on MSI's AMD 9-Series motherboards. MSI's OC Genie II completely automates advanced overclocking functions and offers up to 248% higher performance with the simple click of a button. It does not matter if you're a first time hardware owner, or a veteran overclocker, activating MSI OC Genie II will unlock your hidden CPU cores, overclock your CPU and your memory to simply give you the best and stable performance for free on MSI AMD 9-Series motherboard available.



Benefits:
-
Automatically overclock & unlock hidden CPU core(s) in 1 second
- Instantly boost system performance up to 248%

featurePic

Military Class II

The perfect trinity of quality, stability and efficiency all exist at one motherboard to meet end user expectations. The MSI Military Class II series products provide the long lifespan, unparalleled quality, extreme performance and ultimate efficiency.


Hi-c CAP
8X Lifespan than solid Capacitor!!
Insisting on the best stability, MSI utilizes Hi-c CAPs on Military Class series.  Made of the rare element Tantalum, often used on space shuttles and satellites, which sustains very high temperatures and shows an amazingly high electrical conductivity.


SFC
SFC(Super Ferrite Choke).The super Ferrite Chokes use a Ferrite core that is Super-Permeable. Compare with traditional choke, the Super Ferrite Chokes run at a 35 degree Celsius lower temperature. The lower working temperature will enhance motherboard stability.



Solid CAP
10 years long lifespan
For providing the highest quality products, we built-in Solid CAP in the entire Military Class series. This not only makes bursting capacitors a non-issue but also ensures a dramatically extended lifetime and ultra-low ESR.

featurePic

THX TruStudio PRO

THX is a trade mark of a high-end audio/visual reproduction standard for movies, home theaters, computer speakers and other audio devices. THX Certified Audio products are designed to let users experience movies & videos as live show. The true sound effect can make high definition video more powerful.

Features
- A high-fidelity sound reproduction standard
- Accurately reproduce the fullest audio experience of movie, music and game soundtracks

featurePic

Super Charger

Mobile consumer appliances are getting more and more attention in current day fast moving life style, with smart phones and tablets almost becoming a fashion accessory. However, many ordinary personal computers cannot charge some of these devices, making it difficult to stay connected.  The MSI Super Charger is a Windows resident program capable of revising the power supply mode of your USB port to become more powerful. Once your phone or tablet is connected to your USB port, the Super Charger sends a signal to initiate its charging circuit, making it a really smart and convenient charging solution for mobile computing needs.

Features
- Instant MB info monitor
- Green Power: CPU Phase, system fan speed controlled with max power saving
- Smart Mode: 4 instant OC modes

featurePic

USB 3.0

Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gb/s offers 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute. MSI also has implemented a front panel USB 3.0 port, making the use of an external USB 3.0 device even more convenient.

Features
- 10X Faster Than USB 2.0
- Up to 5Gb/s Data Transfer Bandwidth
- World’s first to provide Front Panel USB 3.0 Port
- Boost Transfer Rate Between Your PC and External Storage Devices

featurePic

SATA 6Gb/s

SATA 6Gb/s provides double the bandwidth of traditional SATA 3Gb/s, and increases the data transfer rate between your motherboard and internal storage devices, such as 7200RPM HDDs, 10000RPM HDDs and SSDs. It’s also the current trend for upcoming high-speed internal storage devices to to break the existing bottleneck of a PC’s performance.

Features
- 2X Faster Than SATA 3Gb/s
- Up to 6Gb/s Data Transfer Bandwidth
- Unleash True Performance of New HDDs/SSDs

featurePic

APS (Active Phase Switching)

Active Phase Switching, APS, technology is an intelligent design that helps to save energy on MSI’s motherboards. The underlying idea is to switch off the power supply as soon as no electricity is needed, and when the system needs more resources again, APS will automatically adjust electricity supply accordingly. APS will automatically detect your processor’s loading at any given time and save energy accordingly. This is only possible by means of a very advanced power controlling technology. Other than software-based solutions, APS technology stands out from MSI's own research. The specially developed IC chip can operate automatically depending on the demands of the power supply, which is to reduce the total power usage.


featurePic

M-Flash

Compared to common motherboard which need extra BIOS chips, MSI’s M-Flash has a double advantage which doesn’t need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover it can also be seen as a portable BIOS chip which is actually able to boot up your PC.

Features
- Backup/Restore Your BIOS to/from Any USB Flash Disk
- Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process
- Earn more BIOS Lifespan by Reducing Unnecessary Rewriting Process

featurePic

USB Safeguard

USB Safeguard can prevent motherboards and USB devices from being damaged by short-circuit and ESD (Electro-Static Discharge) with Anti-ESD chips built-into the motherboards. Additionally, the safeguard can protect against such dangers multiple times, and greatly improves product lifespan.

Features
- All MSI motherboards use USB Safeguard’s anti-ESD chip for thorough protection against ESD damage
- USB Safeguard is protected against a short circuit and/or ESD without the need for a fuse. It also supports stand-by power supply

featurePic

AMD CrossFireX

AMD CrossFireX™ is the ultimate multi-GPU performance gaming platform. Enabling game-dominatig power, AMD CrossFireX technology enables two or more discrete graphics processors to work together to improve graphics performance. AMD CrossFireX technology allows you to expand your system’s graphics capabilities. It allows you the ability to scale your system’s graphics horsepower as you need it, supporting up to four AMD Radeon™ HD graphics cards, making it the most scalable gaming platform ever. With an AMD CrossFireX gaming technology, the traditional graphics limitation exists no more, allowing you to enjoy higher performance as well as visual experience.

featurePic

Live Update 5

MSI Live Update 5 is a powerful and useful application for updating the latest BIOS and Drivers, saving you time and lowers the risk of updating. End-users can install and run the Live Update 5 software on their computers with the companion CD or downloading the app from the MSI website.

Features
- Automatically Detect the BIOS/Driver/VGA/Utility Update
- Support Microsoft Windows 98SE/ME/2000/XP/Vista/7 32Bit


featurePic

NVIDIA SLI

SLI technology allows using multiple Nvidia graphics cards in a single computer system with a motherboard equipped with an nForce SLI MCP. Users need an a motherboard with two PCI-Express 16x graphics slots and two matching GeForce graphics cards which are "SLI Ready". Most NVIDIA's PCI-Express graphics cards starting from the 6600 GPU can enjoy the benefits of SLI.

featurePic

DrMOS

In order to provide customers stable and high quality products, starting from P45 series motherboards, MSI is leading the industry to introduce the world's most advanced power supply component, DrMOS (Driver-MOSFET), which integrates Driver IC, Top MOSFET and Bottom MOSFET into one chip. Except for its outstanding performance in power saving, DrMOS possesses switch frequency which is 400% faster than traditional MOSFET and has great improvement in stabilizing power supply and voltage control. Even under heavy loading and overclocking conditions, DrMOS can still provide the most stable and efficient power supply and quality.

featurePic

Cool'n'Quiet

AMD Cool'n'Quiet™ Technology reduces heat and noise so you can experience amazing performance without distraction. Combined with core enhancements, included in the AMD processors, that can improve overall power savings, deliver better multitasking and energy efficiency. Cool'n'Quiet technology can automatically adjust processor ratio to throttle CPU speed with four modes.

Features
- Independent Dynamic Core Technology
- Dual Dynamic Power Management™
- AMD CoolCore™ Technology
- AMD Wideband Frequency Control
- Multi-Point Thermal Control

featurePic

3TB+ Infinity

3TB+ Infinity is not only breaking through the limit of traditional BIOS, but also enhancing the utilization of hard drives efficiently. In addition to supporting the latest 3TB hard drives, MSI 3TB+ Infinity technology can use the 3TB hard drive as boot disk when installing a 64-bit operating system. Compared to competitors, MSI 3TB+ Infinity is an industry-leading technology which substantially presents an advantage of development and application in the future.

Features
- All the latest 3TB hard drivers on the market can be supported
- Make the 3TB hard drive as boot disk when installing a 64-bit operating system

MSI Reminds You...

  1. The specifications may differ from areas and we keep the right to change without notice. Please check the specific Specification with your local dealers.
  2. The color of the product might be affected by photography and the monitor's setting, which might be different from the real product.

featurePic

Lossless 24-bit/192KHz HD Audio

Onboard PC audio gets better! MSI is the first to implement the most high-end HD Audio codecs available. Don’t be fooled by other inferior audio solutions onboard (sometimes you can’t even find the driver!) Only MSI offers the Loss-less 24-bit/192KHz HD Audio function with an incredible 109 SNR dB value to provide the most clear & vivid HD audio quality and support 7.1 channels surround sound playback with a 2-channel independent stereo output (multiple streaming) through the front panel 3.5 inch phone jack.




featurePic

Winki 3

Winki 3 is a free Linux-based O/S which is based on the Linux core. With an ultra-fast  booting speed and a multi-language interface, the built-in Winki 3 provides an easy-to-use internet environment that includes the most popular functions such as internet surfing, web mail, instant messaging, picture browsing, and more. It's the most practical way to be online in the shortest time.

Features
- User friendly & totally free applications
- Power on to run applications in 25 seconds
- Multi-language interface support

featurePic

OC Genie II – Overclock & Unlock CPU Core in 1 Second

OC Genie II, the most powerful and easy overclocking technology is implemented on MSI's AMD 9-Series motherboards. MSI's OC Genie II completely automates advanced overclocking functions and offers up to 248% higher performance with the simple click of a button. It does not matter if you're a first time hardware owner, or a veteran overclocker, activating MSI OC Genie II will unlock your hidden CPU cores, overclock your CPU and your memory to simply give you the best and stable performance for free on MSI AMD 9-Series motherboard available.



Benefits:
-
Automatically overclock & unlock hidden CPU core(s) in 1 second
- Instantly boost system performance up to 248%

featurePic

Military Class II

The perfect trinity of quality, stability and efficiency all exist at one motherboard to meet end user expectations. The MSI Military Class II series products provide the long lifespan, unparalleled quality, extreme performance and ultimate efficiency.


Hi-c CAP
8X Lifespan than solid Capacitor!!
Insisting on the best stability, MSI utilizes Hi-c CAPs on Military Class series.  Made of the rare element Tantalum, often used on space shuttles and satellites, which sustains very high temperatures and shows an amazingly high electrical conductivity.


SFC
SFC(Super Ferrite Choke).The super Ferrite Chokes use a Ferrite core that is Super-Permeable. Compare with traditional choke, the Super Ferrite Chokes run at a 35 degree Celsius lower temperature. The lower working temperature will enhance motherboard stability.



Solid CAP
10 years long lifespan
For providing the highest quality products, we built-in Solid CAP in the entire Military Class series. This not only makes bursting capacitors a non-issue but also ensures a dramatically extended lifetime and ultra-low ESR.

featurePic

THX TruStudio PRO

THX is a trade mark of a high-end audio/visual reproduction standard for movies, home theaters, computer speakers and other audio devices. THX Certified Audio products are designed to let users experience movies & videos as live show. The true sound effect can make high definition video more powerful.

Features
- A high-fidelity sound reproduction standard
- Accurately reproduce the fullest audio experience of movie, music and game soundtracks

featurePic

Super Charger

Mobile consumer appliances are getting more and more attention in current day fast moving life style, with smart phones and tablets almost becoming a fashion accessory. However, many ordinary personal computers cannot charge some of these devices, making it difficult to stay connected.  The MSI Super Charger is a Windows resident program capable of revising the power supply mode of your USB port to become more powerful. Once your phone or tablet is connected to your USB port, the Super Charger sends a signal to initiate its charging circuit, making it a really smart and convenient charging solution for mobile computing needs.

Features
- Instant MB info monitor
- Green Power: CPU Phase, system fan speed controlled with max power saving
- Smart Mode: 4 instant OC modes

featurePic

USB 3.0

Compared to the 480Mbps provided by traditional USB 2.0, the all-new USB 3.0's 5Gb/s offers 10 times the transfer bandwidth, so transferring a Blu-ray movie takes less than one minute. MSI also has implemented a front panel USB 3.0 port, making the use of an external USB 3.0 device even more convenient.

Features
- 10X Faster Than USB 2.0
- Up to 5Gb/s Data Transfer Bandwidth
- World’s first to provide Front Panel USB 3.0 Port
- Boost Transfer Rate Between Your PC and External Storage Devices

featurePic

SATA 6Gb/s

SATA 6Gb/s provides double the bandwidth of traditional SATA 3Gb/s, and increases the data transfer rate between your motherboard and internal storage devices, such as 7200RPM HDDs, 10000RPM HDDs and SSDs. It’s also the current trend for upcoming high-speed internal storage devices to to break the existing bottleneck of a PC’s performance.

Features
- 2X Faster Than SATA 3Gb/s
- Up to 6Gb/s Data Transfer Bandwidth
- Unleash True Performance of New HDDs/SSDs

featurePic

APS (Active Phase Switching)

Active Phase Switching, APS, technology is an intelligent design that helps to save energy on MSI’s motherboards. The underlying idea is to switch off the power supply as soon as no electricity is needed, and when the system needs more resources again, APS will automatically adjust electricity supply accordingly. APS will automatically detect your processor’s loading at any given time and save energy accordingly. This is only possible by means of a very advanced power controlling technology. Other than software-based solutions, APS technology stands out from MSI's own research. The specially developed IC chip can operate automatically depending on the demands of the power supply, which is to reduce the total power usage.


featurePic

M-Flash

Compared to common motherboard which need extra BIOS chips, MSI’s M-Flash has a double advantage which doesn’t need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover it can also be seen as a portable BIOS chip which is actually able to boot up your PC.

Features
- Backup/Restore Your BIOS to/from Any USB Flash Disk
- Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process
- Earn more BIOS Lifespan by Reducing Unnecessary Rewriting Process

featurePic

USB Safeguard

USB Safeguard can prevent motherboards and USB devices from being damaged by short-circuit and ESD (Electro-Static Discharge) with Anti-ESD chips built-into the motherboards. Additionally, the safeguard can protect against such dangers multiple times, and greatly improves product lifespan.

Features
- All MSI motherboards use USB Safeguard’s anti-ESD chip for thorough protection against ESD damage
- USB Safeguard is protected against a short circuit and/or ESD without the need for a fuse. It also supports stand-by power supply

featurePic

AMD CrossFireX

AMD CrossFireX™ is the ultimate multi-GPU performance gaming platform. Enabling game-dominatig power, AMD CrossFireX technology enables two or more discrete graphics processors to work together to improve graphics performance. AMD CrossFireX technology allows you to expand your system’s graphics capabilities. It allows you the ability to scale your system’s graphics horsepower as you need it, supporting up to four AMD Radeon™ HD graphics cards, making it the most scalable gaming platform ever. With an AMD CrossFireX gaming technology, the traditional graphics limitation exists no more, allowing you to enjoy higher performance as well as visual experience.

featurePic

Live Update 5

MSI Live Update 5 is a powerful and useful application for updating the latest BIOS and Drivers, saving you time and lowers the risk of updating. End-users can install and run the Live Update 5 software on their computers with the companion CD or downloading the app from the MSI website.

Features
- Automatically Detect the BIOS/Driver/VGA/Utility Update
- Support Microsoft Windows 98SE/ME/2000/XP/Vista/7 32Bit


featurePic

NVIDIA SLI

SLI technology allows using multiple Nvidia graphics cards in a single computer system with a motherboard equipped with an nForce SLI MCP. Users need an a motherboard with two PCI-Express 16x graphics slots and two matching GeForce graphics cards which are "SLI Ready". Most NVIDIA's PCI-Express graphics cards starting from the 6600 GPU can enjoy the benefits of SLI.

featurePic

DrMOS

In order to provide customers stable and high quality products, starting from P45 series motherboards, MSI is leading the industry to introduce the world's most advanced power supply component, DrMOS (Driver-MOSFET), which integrates Driver IC, Top MOSFET and Bottom MOSFET into one chip. Except for its outstanding performance in power saving, DrMOS possesses switch frequency which is 400% faster than traditional MOSFET and has great improvement in stabilizing power supply and voltage control. Even under heavy loading and overclocking conditions, DrMOS can still provide the most stable and efficient power supply and quality.

featurePic

Cool'n'Quiet

AMD Cool'n'Quiet™ Technology reduces heat and noise so you can experience amazing performance without distraction. Combined with core enhancements, included in the AMD processors, that can improve overall power savings, deliver better multitasking and energy efficiency. Cool'n'Quiet technology can automatically adjust processor ratio to throttle CPU speed with four modes.

Features
- Independent Dynamic Core Technology
- Dual Dynamic Power Management™
- AMD CoolCore™ Technology
- AMD Wideband Frequency Control
- Multi-Point Thermal Control

featurePic

3TB+ Infinity

3TB+ Infinity is not only breaking through the limit of traditional BIOS, but also enhancing the utilization of hard drives efficiently. In addition to supporting the latest 3TB hard drives, MSI 3TB+ Infinity technology can use the 3TB hard drive as boot disk when installing a 64-bit operating system. Compared to competitors, MSI 3TB+ Infinity is an industry-leading technology which substantially presents an advantage of development and application in the future.

Features
- All the latest 3TB hard drivers on the market can be supported
- Make the 3TB hard drive as boot disk when installing a 64-bit operating system

Basic Specification

CPU (Max Support) Phenom II
AM3 CPU Ready Y
FSB / Hyper Transport Bus up to 5200MT/s
Chipset AMD® 990FX+SB950
DDR3 Memory DDR3 800/1066/1333/1600/1800*/2133*(OC)
Memory Channel Dual
DIMM Slots 4
Max Memory (GB) 32
PCI-Ex16 4
PCI-E Gen Gen2 (2x16, 1x8, 1x4)
PCI-Ex1 2
PCI 1
SATAIII 6
RAID 0/1/5/10
LAN 10/100/1000*1
TPM 1
USB 3.0 ports (Rear) 2
USB 2.0 ports (Rear) 6
Audio ports (Rear) 6+Coaxial SPDIF/Optical SPDIF
1394 ports (Rear) 1
eSATA 2
Form Factor ATX
DrMOS Y
APS Y
SLI Y
3-way SLI Y
CrossFire Y



The Specification may change without notice. The actual products sold are different from areas. Please check the detailed Specification with your local dealers.



Detail Specification




CPU

• 64bit AMD® Phenom II X8/X6/X4/X3/X2, Athlon II X4/X3/X2 and Sempron CPU in AM3 / AM3+ package.
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Hyper Transport Bus

• HyperTransport 3.0 supporting speed up to 5200MT/s

Chipset

• AMD® 990FX and SB950 Chipset


Main Memory

• Supports four unbuffered DIMM of 1.5 Volt DDR3 800/1066/1333/1600/1800*/2133* (OC) DRAM, 32GB Max



Slots

• 4 PCI Express 2.0 x16 slots
• 2 PCI Express 2.0 x1 slots
• 1 PCI slot, support 3.3V/ 5V PCI bus Interface.


On-Board SATA

• 6 SATA III (1~6) ports by AMD® SB950
- Supports storage and data transfers at up to 6Gb/s

RAID Function

- SATA III 1~6 support RAID 0, 1, 5, 10 mode by AMD® SB950

MSI Reminds You...
• The RAID setup floppy disk is optional depending on the districts. You can download the files from the website to make the setup disk.


USB 3.0

• 2 USB 3.0 ports by NEC® D720200



Audio

• Chipset integrated by Realtek® ALC892
- True Blu-ray Audio Support
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec



LAN

• Realtek PCI-E GbLAN controller 8111E
- Integrated Fast Ethernet MAC and PHY in single chip
- Supports 10Mb/s, 100Mb/s and 1000Mb/s
- Compliance with PCI-Express Bus specification v1.0a



IEEE1394 / FireWire

VIA® VT6315N chipset
- Supports up to two 1394 ports. (pinheader x2)
- Transfer rate is up to 400Mbps.



Internal I/O Connectors

- 1 x ATX 24-pin power connector
- 1 x ATX 8-pin 12V CPU power connector
- CPU x 1 / System x 4 FAN connectors
- 1 x Front panel audio connector
- 1 x Front panel connector
- 1 x Chassis intrusion switch connector
- 2 x USB 2.0 connectors
- 1 x USB 3.0 connector
- 6 x Serial ATA III connectors
- 1 x IEEE1394 connector
- 1 x Serial port connector
- 1 x Power button
- 1 x Reset button
- 1 x OC Genie button
- 1 x Debug LED display
- 1 x Clear CMOS jumper
- 1 x SPDIF-out connector
- 1 x TPM module connector



Back Panel I/O Ports

- 1 x PS/2 Keyboard port
- 1 x PS/2 Mouse port
- 1 x Claer CMOS button
- 1 x Coaxial SPDIF-out
- 1 x Optical SPDIF-out
- 4 x USB 2.0 ports
- 2 x USB 3.0 ports (blue)
- 2 x eSATA / USB 2.0 Combo ports
- 1 x RJ45 LAN Jacks
- 1 x 6 in 1 audio jack



Dimension

• 30.5cm(L) x 24.4cm(W) ATX Form Factor

Mounting

• 9 mounting holes.





The Specification may change without notice. The actual products sold are different from areas. Please check the detailed Specification with your local dealers.



Awards

the Bronze Award - Hardware-Test
Date: 2012-00
Title: the Bronze Award
Comment: >Open
Media: Hardware-Test
Country: Denmark
We liked it! - HardwareOC.hu
Date: 2012-00
Title: We liked it!
Comment: >Open
Media: HardwareOC.hu
Country: Hungary
TIP CHOICE Award - CHIP
Date: 2011-00
Title: TIP CHOICE Award
Comment: -
Media: CHIP
Country: Indonesia
Silver Award - OverclockersClub
Date: 2011-00
Title: Silver Award
Comment: >Open
Media: OverclockersClub
Country: United States
Golden Tachometer Award! - Benchmark Reviews
Date: 2011-00
Title: Golden Tachometer Award!
Comment: >Open
Media: Benchmark Reviews
Country: United States
Best Value - TweakTown
Date: 2011-00
Title: Best Value
Comment: >Open
Media: TweakTown
Country: Australia
Best Performance - PCnet Magazine
Date: 2011-00
Title: Best Performance
Comment: -
Media: PCnet Magazine
Country: Turkey
Gold Award - Worldoc
Date: 2011-00
Title: Gold Award
Comment: >Open
Media: Worldoc
Country: Italy
Good Produc - Benchmark.pl
Date: 2011-00
Title: Good Produc
Comment: >Open
Media: Benchmark.pl
Country: Poland
Top Values Award - OC Team Denmark
Date: 2011-00
Title: Top Values Award
Comment: >Open
Media: OC Team Denmark
Country: Denmark
Overclock Approved - Worldoc
Date: 2011-00
Title: Overclock Approved
Comment: >Open
Media: Worldoc
Country: Italy

BIOS

!Attention:

Users who download BIOS from here (not using Live Update) should use the flash utility included in the downloaded compressed file when doing the BIOS update. To avoid BIOS update failure, please do not use older versions of the update utility or utilities not provided by MSI.

We suggest using Chrome, Firefox 3.0 or IE 8.0 above browsers to download BIOS, Drivers, etc.
Description - Update CPU AGESA code.
Version 13.5
Type BIOS Release Date 2013-09-26
Download download File Size 7.84 MB
Note * Please download and execute the file in USB pen drive only.
System will restart several times to update system BIOS with NVRAM & ROMHOLE.
Please DO NOT remove the USB pen drive until BIOS updated successfully.
* Please make sure you have read the SOP before you update the BIOS.
* MSI recommend you to update BIOS only if you are using Windows8.
* There is no way to reflash back to BIOS version Bxx if you already updated to version Dxx.
About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA Code.
Version 13.4
Type BIOS Release Date 2013-07-22
Download download File Size 7.83 MB
Note * Please download and execute the file in USB pen drive only.
System will restart several times to update system BIOS with NVRAM & ROMHOLE.
Please DO NOT remove the USB pen drive until BIOS updated successfully.
* Please make sure you have read the SOP before you update the BIOS.
* MSI recommend you to update BIOS only if you are using Windows8.
* There is no way to reflash back to BIOS version Bxx if you already updated to version Dxx.
About how to flash the BIOS, please refer to BIOS flash SOP
Description - Enhanced system stablity.
Version 13.3
Type BIOS Release Date 2013-04-23
Download download File Size 7.82 MB
Note * Please download and execute the file in USB pen drive only.
System will restart several times to update system BIOS with NVRAM & ROMHOLE.
Please DO NOT remove the USB pen drive until BIOS updated successfully.
* Please make sure you have read the SOP before you update the BIOS.
* MSI recommend you to update BIOS only if you are using Windows8.
* There is no way to reflash back to BIOS version Bxx if you already updated to version Dxx.
About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA code.
- Improved memory compatibility.
Version 11.13
Type AMI BIOS Release Date 2012-10-09
Download download File Size 3.18 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Improved gaming keyboard compatibility.
- Support RocketRAID 640 card.

Version 11.12
Type AMI BIOS Release Date 2012-07-24
Download download File Size 3.17 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Improved memory compatibility.
Version 11.11
Type AMI BIOS Release Date 2012-06-11
Download download File Size 3.18 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Enhance OC performance.
Version 11.10
Type AMI BIOS Release Date 2012-04-25
Download download File Size 3.18 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA code.
- Improved memory compatibility.
Version 11.9
Type AMI BIOS Release Date 2012-03-27
Download download File Size 3.18 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA code.
- Update M-Flash module.
- Update USB module.
Version 11.8
Type AMI BIOS Release Date 2011-12-15
Download download File Size 3.15 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update ClickBIOS code.
- Add system fan control item.
- Improved memory compatibility.
Version 11.7
Type AMI BIOS Release Date 2011-11-25
Download download File Size 3.13 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA code.
- Add buzzer beep warning message with memory unplugged.
- Improved memory compatibility.
- Improved gaming mouse compatibility.
Version 11.6
Type AMI BIOS Release Date 2011-10-24
Download download File Size 3.07 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU AGESA code.
- Update memory module.
- Update RAID ROM version.
- Update USB module.
- Enhance CPU smart fan function.
Version 11.5
Type AMI BIOS Release Date 2011-09-19
Download download File Size 2.95 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU module.
Version 11.4
Type AMI BIOS Release Date 2011-08-25
Download download File Size 2.93 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update NB module.
- Improved memory compatibility.
Version 11.2
Type AMI BIOS Release Date 2011-07-06
Download download File Size 1.88 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description - Update CPU module.
- Update USB module.
Version 11.1
Type AMI BIOS Release Date 2011-06-09
Download download File Size 1.88 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
Description New BIOS Release
Version 11.0
Type AMI BIOS Release Date 2011-05-26
Download download File Size 1.88 MB
Note About how to flash the BIOS, please refer to BIOS flash SOP
click here

Live Update 5

DISCLAIMER:
Live Update 5 utility is only intended for MSI Desktop PC related products (mainboards and graphics cards) usage. This utility doesn’t support any MSI Notebook (NB and Tablet PC) or AIO product, while installed might experience unexpected errors. If it happens that you have installed Live Update 5 on your Notebook or AIO system, please uninstall it then perform system restart.

Live Update 5 is a powerful update tool with user-friendly interface, provides an automatic scan and download for your MSI products. Using this service to keep your system in the most updated environment.

Live Update 5 supports the following MSI product lines and items:
Mainboards: Drivers/BIOS/Utilities;
Graphics Cards: Drivers/BIOS

Click here to read the instruction

Driver

Win8 32,Win8 64,Win7 32,Win7 64,Vista 32,Vista 64,XP 32,XP 64,Win 98 SE

!Special Note:

The Drivers provided here are exclusively for MSI products only. MSI takes no responsibility for any damage resulted from improper usage or lack of technical expertise.

We suggest using Chrome, Firefox 3.0 or IE 8.0 above browsers to download BIOS, Drivers, etc.
AMD Cool and Quiet Driver (MB)
Description • AMD Athlon™ 64/Sempron™/Turion™ 64/Opteron™ systems with ACPI 2.0 processor performance control objects
• WinXP WHQL pass
• Driver Version:
- XP 1.2.2.0
- 98/ME/2K 1.0.8.1
• Windows XP 64-Bit Edition or Windows Server 2003 64-Bit Edition

Version
Type Others Drivers Release Date 2006-02-20
OS Win 98 SE
Download download File Size 0 MB
Note
AMD Cool and Quiet Driver (MB)
Description • AMD Athlon™ 64/Sempron™/Turion™ 64/Opteron™ systems with ACPI 2.0 processor performance control objects
• WinXP WHQL pass
• Driver Version:
- XP 1.2.2.0
- 98/ME/2K 1.0.8.1
• Windows XP 64-Bit Edition or Windows Server 2003 64-Bit Edition

Version
Type Others Drivers Release Date 2006-02-20
OS XP 32
Download download File Size 0 MB
Note
AMD Cool and Quiet Driver (MB)
Description • AMD Athlon™ 64/Sempron™/Turion™ 64/Opteron™ systems with ACPI 2.0 processor performance control objects
• WinXP WHQL pass
• Driver Version:
- XP 1.2.2.0
- 98/ME/2K 1.0.8.1
• Windows XP 64-Bit Edition or Windows Server 2003 64-Bit Edition

Version
Type Others Drivers Release Date 2006-02-20
OS XP 64
Download download File Size 0 MB
Note
AMD RAID Driver
Description AMD 9xx RAID Driver
Version 3.3.1540.22
Type On-Board PIDE/SATA Drivers Release Date 2012-03-19
OS Win7 32, Win7 64, Vista 32, Vista 64
Download download File Size 0.91 MB
Note
Realtek High Definition Audio Driver
Description • Realtek High Definition Audio System Software
• WinXP Driver Version: 5.10.0.6586
• Windows 7/Vista Version: 6.0.1.6586
Version 6.0.1.7111
Type On-Board Audio Drivers Release Date 2013-12-09
OS Win8 64, Win8 32, Win7 32, Win7 64, Vista 32, Vista 64, XP 32, XP 64
Download download File Size 220.59 MB
Note
Realtek PCI-E Ethernet Drivers
Description Network Driver
Version 7.77.1126.2013
Type On-Board LAN Drivers Release Date 2014-03-13
OS Win7 32, Win7 64
Download download File Size 5.86 MB
Note
Realtek PCI-E Ethernet Drivers
Description
Version 5.818.912.2013
Type On-Board LAN Drivers Release Date 2013-10-30
OS XP 32, XP 64
Download download File Size 5.69 MB
Note
Realtek PCI-E Ethernet Drivers
Description
Version 6.252.1109.2012
Type On-Board LAN Drivers Release Date 2013-05-10
OS Vista 32, Vista 64
Download download File Size 5.69 MB
Note
ATI System Drivers for 7xx/8xx/SB7xx/SB8xx Series (except RS690, 740)
Description ATI System & VGA Drivers
Version 8.881.0.0
Type System & Chipset Drivers Release Date 2012-09-20
OS XP 32, XP 64
Download download File Size 361.55 MB
Note
Renesas USB3.0 Drivers
Description
Version 2.0.34.0
Type System & Chipset Drivers Release Date 2012-07-12
OS Win7 32, Win7 64, Vista 32, Vista 64, XP 32, XP 64
Download download File Size 16.04 MB
Note

Utility

Win8 32,Win8 64,Win7 32,Win7 64,Vista 32,Vista 64,XP 32,XP 64,Win 2000,Win 98,Win 98 SE,Win Me,Win 95,DOS

!Special Note:

The Utilities provided here are exclusively for MSI products only. MSI takes no responsibility for any damage resulted from improper usage or lack of technical expertise.

We suggest using Chrome, Firefox 3.0 or IE 8.0 above browsers to download BIOS, Drivers, etc.
Live Update 5
Description • Online update BIOS/Driver/Firmware/Utility.
• Live Monitor auto-detects and suggests the latest BIOS/Driver/Utilities information.
Version 5.0.115
Type Utility Release Date 2014-04-03
OS Win8 64, Win8 32, Win7 32, Win7 64, Vista 32, Vista 64, XP 32, XP 64
Download download File Size 9.64 MB
Note
Control Center
Description 1. utility for msi products to overclock & greenpower
2. note:need install Intel ME driver to enable CPU overclock
Version 2.5.060
Type Utility Release Date 2013-10-23
OS Win8 64, Win8 32, Win7 32, Win7 64, Vista 32, Vista 64, XP 32, XP 64
Download download File Size 24.75 MB
Note
THX TruStudio PRO
Description THX TruStudio PRO
Version 1.04.03
Type Utility Release Date 2013-08-22
OS Win8 64, Win8 32, Win7 32, Win7 64, Vista 32, Vista 64
Download download File Size 12.85 MB
Note
xxx
Description 1. utility for msi products to charge Apple iPad/iPhone4.
Version 1.2.014
Type Utility Release Date 2012-11-14
OS Win8 64, Win8 32, Win7 32, Win7 64, Vista 32, Vista 64, XP 32, XP 64
Download N/A File Size 0.02 MB
Note
AutoBoot
Description Utility for PC power schedule, alarm clock, auto login
Version 1.0.103
Type Utility Release Date 2009-09-08
OS Vista 32, Vista 64, XP 32
Download download File Size 2.22 MB
Note
HDDBackup
Description 1. For System Backup
2. Please use Nero to burn the Image to boot up the system for backup.
Version 1.25
Type Utility Release Date 2008-07-30
OS DOS
Download download File Size 43.56 MB
Note
AMD CPU Tool
Description This tool will provide stable performance for AMD AM2 CPU.
Version 1.3.2.16
Type Utility Release Date 2007-01-09
OS XP 32, Win 2000, Win 98, Win 98 SE, Win Me, Win 95
Download download File Size 6.27 MB
Note
ATI RAID Tool
Description This is for setting up ATI RAID function.
Version 2.5.1540.4
Type Utility Release Date 2006-11-02
OS XP 32
Download download File Size 32.04 MB
Note

Manual

!Special Note:

MSI™ provides user manuals (in PDF format) here for download. You can use Adobe Acrobat Reader (Adobe's WEB Site) to open them.

An easy guide for you to assemble your PC step by step, please refer to "Quick Installation Guide".

We suggest using Chrome, Firefox 3.0 or IE 8.0 above browsers to download BIOS, Drivers, etc.
Version Language File Size Download Release Date
1.0 English 6.12 MB download 2012-02-21
2.0 Multi-Language 8.66 MB download 2011-05-17
2.0 Multi-Language 14.17 MB download 2011-05-17
2.0 English 5.31 MB download 2011-05-10

Quick Guide

\"!\"Special Note:

MSI™ provides user manuals (in PDF format) here for download. You can use Adobe Acrobat Reader (Adobe's WEB Site) to open them.

We suggest using Chrome, Firefox 3.0 or IE 8.0 above browsers to download BIOS, Drivers, etc.
Version Language File Size Download Release Date
1.5 English 5.85 MB download 2012-03-09

CPU Support

Processor Core Name CPU Code CPU No FSB CPU Speed L2 L3 Stepping Wattage GPU Result
Athlon II Sargas AD170UEAK13GM 170u 200 2.00 1M N/A C3 20   7640vB5.zip
Athlon II X2 Regor ADX280OCK23GM x280 200 3.60 2M N/A C3 65   7640vBD.zip
Athlon II X2 Regor ADX275OCK23GM x275 200 3.50 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX270OCK23GM x270 200 3.40 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX265OCK23GM x265 200 3.30 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX260OCK23GM x260 200 3.20 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX255OCK23GM x255 200 3.10 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX255OCK23GQ x255 200 3.10 2M N/A C2 65   7640vB5.zip
Athlon II X2 Regor ADX250OCK23GM x250 200 3.00 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX250OCK23GQ x250 200 3.00 2M N/A C2 65   7640vB5.zip
Athlon II X2 Regor ADX245OCK23GM x245 200 2.90 2M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX245OCK23GQ x245 200 2.90 2M N/A C2 65   7640vB5.zip
Athlon II X2 Regor ADX240OCK23GQ x240 200 2.80 2M N/A C2 65   7640vB5.zip
Athlon II X2 Regor ADX225OCK22GM x225 200 2.90 1M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX220OCK22GM x220 200 2.80 1M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX215OCK22GM x215 200 2.70 1M N/A C3 65   7640vB5.zip
Athlon II X2 Regor ADX215OCK22GQ x215 200 2.70 1M N/A C2 65   7640vB5.zip
Athlon II X2 Regor AD260USCK23GM 260u 200 1.80 2M N/A C3 25   7640vB5.zip
Athlon II X2 Regor AD255EHDK23GM 255e 200 3.10 2M N/A C3 45   7640vB5.zip
Athlon II X2 Regor AD250USCK23GQ 250u 200 1.60 2M N/A C2 25   7640vB9.zip
Athlon II X2 Regor AD250EHDK23GM 250e 200 3.00 2M N/A C3 45   7640vB5.zip
Athlon II X2 Regor AD245EHDK23GM 245e 200 2.90 2M N/A C3 45   7640vB5.zip
Athlon II X2 Regor AD240EHDK23GM 240e 200 2.80 2M N/A C3 45   7640vB5.zip
Athlon II X2 Regor AD240EHDK23GQ 240e 200 2.80 2M N/A C2 45   7640vB5.zip
Athlon II X2 Regor AD235EHDK23GQ 235e 200 2.70 2M N/A C2 45   7640vB5.zip
Athlon II X3 Rana ADX460WFK32GM x460 200 3.40 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX455WFK32GM x455 200 3.30 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX450WFK32GM x450 200 3.20 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX445WFK32GM x445 200 3.10 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX440WFK32GI x440 200 3.00 1.5M N/A C2 95   7640vB5.zip
Athlon II X3 Rana ADX440WFK32GM x440 200 3.00 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX435WFK32GI x435 200 2.90 1.5M N/A C2 95   7640vB5.zip
Athlon II X3 Rana ADX435WFK32GM x435 200 2.90 1.5M N/A C3 95   7640vB5.zip
Athlon II X3 Rana ADX425WFK32GI x425 200 2.70 1.5M N/A C2 95   7640vB5.zip
Athlon II X3 Rana AD425EHDK32GM 425e 200 2.70 1.5M N/A C3 45   7640vB5.zip
Athlon II X3 Rana AD420EHDK32GM 420e 200 2.60 1.5M N/A C3 45   7640vB5.zip
Athlon II X3 Rana AD415EHDK32GM 415e 200 2.50 1.5M N/A C3 45   7640vB5.zip
Athlon II X3 Rana AD405EHDK32GI 405e 200 2.30 1.5M N/A C2 45   7640vB5.zip
Athlon II X3 Rana AD405EHDK32GM 405e 200 2.30 1.5M N/A C3 45   7640vB5.zip
Athlon II X3 Rana AD400EHDK32GI 400e 200 2.20 1.5M N/A C2 45   7640vB5.zip
Athlon II X4 Propus ADX655WFK42GM x655 200 3.30 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX650WFK42GM x650 200 3.20 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX645WFK42GM x645 200 3.10 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX640WFK42GM x640 200 3.00 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX640WFK42GR x640 200 3.00 2M N/A E0 95   7640vB5.zip
Athlon II X4 Propus ADX635WFK42GI x635 200 2.90 2M N/A C2 95   7640vB5.zip
Athlon II X4 Propus ADX635WFK42GM x635 200 2.90 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX630WFK42GI x630 200 2.80 2M N/A C2 95   7640vB5.zip
Athlon II X4 Propus ADX630WFK42GM x630 200 2.80 2M N/A C3 95   7640vB5.zip
Athlon II X4 Propus ADX620WFK42GI x620 200 2.60 2M N/A C2 95   7640vB5.zip
Athlon II X4 Propus AD620EHDK42GM 620e 200 2.60 2M N/A C3 45   7640vB5.zip
Athlon II X4 Propus AD615EHDK42GM 615e 200 2.50 2M N/A C3 45   7640vB5.zip
Athlon II X4 Propus AD610EHDK42GM 610e 200 2.40 2M N/A C3 45   7640vB5.zip
Athlon II X4 Propus AD605EHDK42GI 605e 200 2.30 2M N/A C2 45   7640vB5.zip
Athlon II X4 Propus AD605EHDK42GM 605e 200 2.30 2M N/A C3 45   7640vB5.zip
Athlon II X4 Propus AD600EHDK42GI 600e 200 2.20 2M N/A C2 45   7640vB5.zip
FX-Series Vishera FD8350FRW8KHK FX-8350 200 4.00 8M 8M C0 125   7640vD3.zip
FX-Series Vishera FD8320FRW8KHK FX-8320 200 3.50 8M 8M C0 125   7640vBD.zip
FX-Series Vishera FD8300WMW8KHK FX-8300 200 3.30 8M 8M C0 95   7640vBD.zip
FX-Series Zambezi FD8150FRW8KGU FX-8150 200 3.60 8M 8M B2 125   7640vB5.zip
FX-Series Zambezi FD8140WMW8KGU FX-8140 200 3.20 8M 8M B2 95   7640vB9.zip
FX-Series Zambezi FD8120FRW8KGU FX-8120 200 3.10 8M 8M B2 125   7640vB5.zip
FX-Series Zambezi FD8120WMW8KGU FX-8120 200 3.10 8M 8M B2 95   7640vB5.zip
FX-Series Zambezi FD8100WMW8KGU FX-8100 200 2.80 8M 8M B2 95   7640vB5.zip
FX-Series Vishera FD6350FRW6KHK FX-6350 200 3.90 6M 8M C0 125   7640vBD.zip
FX-Series Vishera FD6300WMW6KHK FX-6300 200 3.50 6M 8M C0 95   7640vBD.zip
FX-Series Zambezi FD6200FRW6KGU FX-6200 200 3.80 6M 8M B2 125   7640vB8.zip
FX-Series Zambezi FD6130FRW6KGU FX-6130 200 3.60 6M 8M B2 125   7640vB9.zip
FX-Series Zambezi FD6120WMW6KGU FX-6120 200 3.50 6M 8M B2 95   7640vB9.zip
FX-Series Zambezi FD6100WMW6KGU FX-6100 200 3.30 6M 8M B2 95   7640vB5.zip
FX-Series Vishera FD4350FRW4KHK FX-4350 200 4.20 4M 8M C0 125   7640vBD.zip
FX-Series Vishera FD4320WMW4MHK FX-4320 200 4.00 4M 4M C0 95   7640vBD.zip
FX-Series Vishera FD4300WMW4MHK FX-4300 200 3.80 4M 4M C0 95   7640vBD.zip
FX-Series Zambezi FD4200FRW4KGU FX-4200 200 3.30 4M 8M B2 125   7640vB9.zip
FX-Series Zambezi FD4170FRW4KGU FX-4170 200 4.20 4M 8M B2 125   7640vB5.zip
FX-Series Zambezi FD4150WMW4KGU FX-4150 200 3.90 4M 8M B2 95   7640vB9.zip
FX-Series Zambezi FD4130FRW4MGU FX-4130 200 3.80 4M 4M B2 125   7640vB9.zip
FX-Series Zambezi FD4100WMW4KGU FX-4100 200 3.60 4M 8M B2 95   7640vB5.zip
Phenom II X2 Callisto HDZ570WFK2DGM z570 200 3.50 1M 6M C3 80   7640vB5.zip
Phenom II X2 Callisto HDZ565WFK2DGM z565 200 3.40 1M 6M C3 80   7640vB5.zip
Phenom II X2 Callisto HDZ560WFK2DGM z560 200 3.30 1M 6M C3 80   7640vB5.zip
Phenom II X2 Callisto HDZ555WFK2DGM z555 200 3.20 1M 6M C3 80   7640vB5.zip
Phenom II X2 Callisto HDZ550WFK2DGI z550 200 3.10 1M 6M C2 80   7640vB5.zip
Phenom II X2 Callisto HDXB59WFK2DGM XB59 200 3.40 1M 6M C3 80   7640vB8.zip
Phenom II X2 Callisto HDX550WFK2DGM x550 200 3.10 1M 6M C3 80   7640vB5.zip
Phenom II X2 Callisto HDX545WFK2DGI x545 200 3.00 1M 6M C2 80   7640vB5.zip
Phenom II X2 Callisto HDX545WFK2DGM x545 200 3.00 1M 6M C3 80   7640vB5.zip
Phenom II X3 Heka HDZ740WFK3DGI z740 200 3.00 1.5M 6M C2 95   7640vB5.zip
Phenom II X3 Heka HDZ720WFK3DGI z720 200 2.80 1.5M 6M C2 95   7640vB5.zip
Phenom II X3 Heka HDX720WFK3DGI x720 200 2.80 1.5M 6M C2 95   7640vB5.zip
Phenom II X3 Heka HDX710WFK3DGI x710 200 2.60 1.5M 6M C2 95   7640vB5.zip
Phenom II X3 Heka HD705EOCK3DGI 705e 200 2.50 1.5M 6M C2 65   7640vB5.zip
Phenom II X3 Heka HD700EOCK3DGI 700e 200 2.40 1.5M 6M C2 65   7640vB5.zip
Phenom II X4 Deneb HDZ980FBK4DGM z980 200 3.70 2M 6M C3 125   7640vB2.zip
Phenom II X4 Deneb HDZ975FBK4DGM z975 200 3.60 2M 6M C3 125   7640vB5.zip
Phenom II X4 Deneb HDZ970FBK4DGM z970 200 3.50 2M 6M C3 125   7640vB5.zip
Phenom II X4 Deneb HDZ965FBK4DGI z965 200 3.40 2M 6M C2 140   7640vB5.zip
Phenom II X4 Deneb HDZ965FBK4DGM z965 200 3.40 2M 6M C3 125   7640vB5.zip
Phenom II X4 Deneb HDZ955FBK4DGI z955 200 3.20 2M 6M C2 125   7640vB5.zip
Phenom II X4 Deneb HDZ955FBK4DGM z955 200 3.20 2M 6M C3 125   7640vB5.zip
Phenom II X4 Deneb HDX960WFK4DGM x960 200 3.30 2M 6M C3 95   7640vB5.zip
Phenom II X4 Deneb HDX955FBK4DGI x955 200 3.20 2M 6M C2 125   7640vB5.zip
Phenom II X4 Deneb HDX955FBK4DGM x955 200 3.20 2M 6M C3 125   7640vB5.zip
Phenom II X4 Deneb HDX955WFK4DGM x955 200 3.20 2M 6M C3 95   7640vB5.zip
Phenom II X4 Deneb HDX945FBK4DGI x945 200 3.00 2M 6M C2 125   7640vB5.zip
Phenom II X4 Deneb HDX945WFK4DGI x945 200 3.00 2M 6M C2 95   7640vB5.zip
Phenom II X4 Deneb HDX945WFK4DGM x945 200 3.00 2M 6M C3 95   7640vB5.zip
Phenom II X4 Deneb HDX925WFK4DGI x925 200 2.80 2M 6M C2 95   7640vB5.zip
Phenom II X4 Deneb HDX925WFK4DGM x925 200 2.80 2M 6M C3 95   7640vB5.zip
Phenom II X4 Deneb HDX910WFK4DGI x910 200 2.60 2M 6M C2 95   7640vB5.zip
Phenom II X4 Deneb HDX850WFK42GM x850 200 3.30 2M N/A C3 95   7640vB2.zip
Phenom II X4 Deneb HDX840WFK42GM x840 200 3.20 2M N/A C3 95   7640vB5.zip
Phenom II X4 Deneb HDX830WFK4DGM x830 200 2.80 2M 6M C3 95   7640vB5.zip
Phenom II X4 Deneb HDX820WFK4FGI x820 200 2.80 2M 4M C2 95   7640vB5.zip
Phenom II X4 Deneb HDX810WFK4FGI x810 200 2.60 2M 4M C2 95   7640vB5.zip
Phenom II X4 Deneb HDX805WFK4FGI x805 200 2.50 2M 4M C2 95   7640vB5.zip
Phenom II X4 Deneb HD960TFBK4DGR 960T 200 3.00 2M 6M E0 125   7640vB9.zip
Phenom II X4 Zosma HD96ZTWFK4DGR 960T 200 3.00 2M 6M E0 95   7640vB5.zip
Phenom II X4 Deneb HD910EOCK4DGM 910e 200 2.60 2M 6M C3 65   7640vB5.zip
Phenom II X4 Deneb HD905EOCK4DGI 905e 200 2.50 2M 6M C2 65   7640vB5.zip
Phenom II X4 Deneb HD905EOCK4DGM 905e 200 2.50 2M 6M C3 65   7640vB5.zip
Phenom II X4 Deneb HD900EOCK4DGI 900e 200 2.40 2M 6M C2 65   7640vB5.zip
Phenom II X4 Zosma HD840TWFK4DGR 840T 200 2.90 2M 6M E0 95   7640vB5.zip
Phenom II X6 Thuban HDE00ZFBK6DGR 1100T 200 3.30 3M 6M E0 125   7640vB5.zip
Phenom II X6 Thuban HDT90ZFBK6DGR 1090T 200 3.20 3M 6M E0 125   7640vB5.zip
Phenom II X6 Thuban HDT75TFBK6DGR 1075T 200 3.00 3M 6M E0 125   7640vB5.zip
Phenom II X6 Thuban HDT65TWFK6DGR 1065T 200 2.90 3M 6M E0 95   7640vB5.zip
Phenom II X6 Thuban HDT55TFBK6DGR 1055T 200 2.80 3M 6M E0 125   7640vB5.zip
Phenom II X6 Thuban HDT55TWFK6DGR 1055T 200 2.80 3M 6M E0 95   7640vB5.zip
Phenom II X6 Thuban HDT45TWFK6DGR 1045T 200 2.70 3M 6M E0 95   7640vB5.zip
Phenom II X6 Thuban HDT35TWFK6DGR 1035T 200 2.60 3M 6M E0 95   7640vB5.zip
Sempron Regor SDX190HDK22GM x190 200 2.50 1M N/A C3 45   7640vB5.zip
Sempron Regor SDX180HDK22GM x180 200 2.40 1M N/A C3 45   7640vB5.zip
Sempron Sargas SDX145HBK13GM x145 200 2.80 1M N/A C3 45   7640vB5.zip
Sempron Sargas SDX140HBK13GQ x140 200 2.70 1M N/A C2 45   7640vB5.zip

Sales Inquiry

MSI is the top 3 motherboard maker with over 20 years solid experience who has built motherboard with high quality and solid stability with a winning reputation from worldwide media and customers for years. Based on the successful experience, MSI began its Enterprise Platform Solution with three product lines of General purpose Server, Blade Server and Network Appliance. In these application domains, MSI provides a series of products from motherboard, barebone, to system to fulfill different needs.

If there is any further request or discussion, welcome to contact us through http://support.msi.com/ and we will reply in soon!
