Aegis R 10th

Show the Differences Aegis R 10SD-076US Aegis R 10SE-078US Aegis R 10SD-053US Aegis R 10SD-016US Aegis R 10SC-017US Aegis R 10SC-210US
Manufacturer Part # AegisR10SD076US AegisR10SE078US AEGISR10SD053 AEGISR10SC016 AEGISR10SC017 AegR10SC210
OS Windows 10 Home Windows 10 Home Windows 10 Home Windows 10 Home Windows 10 Home Windows 10 Home
CPU Intel Core™ i7-10700F Processor 8 Cores 2.9-4.8 GHz 16M Cache Intel Core™ i7-10700F Processor 8 Cores 2.9-4.8 GHz 16M Cache Intel® Core™ i7-10700F Processor 8C/16T 2.90-4.80 GHz 16MB Cache Intel Core™ i7-10700F Processor 8 Cores 2.9-4.8 GHz 16M Cache Intel Core™ i7-10700F Processor 8 Cores 2.9-4.8 GHz 16M Cache Intel® Core™ i7-10700 Processor 8C/16T 2.9-4.8 GHz 16MB Cache
Chipset B460 B460 B460 B460 B460 B460
Motherboard B460M PRO-VDH B460M PRO-VDH MSI MicroATX MB B460M PRO-VDH B460M PRO-VDH MSI MicroATX MB
CPU Cooler Air RGB Cooler Air RGB Cooler A-RGB Fan Cooler Proprietary Thermal Kit included Proprietary Thermal Kit included Air RGB Cooler
VGA NVIDIA® GeForce RTX™ 2070 8G GDDR6 NVIDIA® GeForce RTX™ 2080 8G GDDR6 NVIDIA® GeForce RTX™ 2070 SUPER 8G GDDR6 NVIDIA® GeForce RTX™ 2070 SUPER 8G GDDR6 NVIDIA® GeForce RTX™ 2060 SUPER 8G GDDR6 NVIDIA® GeForce RTX™ 2060 6G GDDR6
Memory (GB) 16GB DDR4 (2 x 8GB) 16GB DDR4 (2 x 8GB) 16GB DDR4 (2 x 8GB) 16GB DDR4 3000Mhz (8GB x 2) 16GB DDR4 3000Mhz (8GB x 2) 16GB DDR4 (2 x 8GB)
LAN 1 x RJ45 (1GbE) RTL8111H 1 x RJ45 (1GbE) RTL8111H 1 x RJ45 (2.5 GbE) Realtek RTL 8125B 1 x RJ45 (2.5 GbE) Realtek RTL 8125B 1 x RJ45 (2.5 GbE) Realtek RTL 8125B 1 x RJ45 (2.5GbE) Realtek RTL8125B
Wireless Communication Intel® Wi-Fi 6 AX200 Dual Band 802.11ax 2x2 Intel® Wi-Fi 6 AX200 Dual Band 802.11ax 2x2 Intel® Wi-Fi 6 AX200 2x2 802.11ax (2.4Gbps) Intel® Wi-Fi 6 AX200 2x2 802.11ax (2.4Gbps) Intel® Wi-Fi 6 AX200 2x2 802.11ax (2.4Gbps) WiFi 6 (802.11ax) 2.4Gbps Dual Band 2.4GHz, 5GHz
Audio 7.1 HD Audio (Realtek ALC892) 7.1 HD Audio (Realtek ALC892) 7.1 Channel HD Audio with Audio Boost 7.1 Channel HD Audio with Audio Boost 7.1 Channel HD Audio with Audio Boost 7.1 HD Audio (Realtek ALC1200) + S/PDIF
Video Port 1xHDMI-out (2.0b), 3x DP-out (1.4) 1xHDMI-out (2.0b), 3x DP-out (1.4) 1xHDMI-out, 3x DisplayPorts
1xHDMI-out, 3x DisplayPorts
1xHDMI-out, 3x DisplayPorts
1xHDMI-out (2.0b), 3x DP-out (1.4)
Expansion Slots 1x PCIe 3.0 x16, 2x PCIe 3.0 x1 1x PCIe 3.0 x16, 2x PCIe 3.0 x1 2x PCI-E 16x 2x PCI-E 16x 2x PCI-E 16x -
USB Front:

2x USB 3.2 Gen 1 Type A

1x fron 3.2 Gen1 Type C



Rear:

4x USB 3.2 Gen 1 Type A

2x USB 2.0
Front:

2x USB 3.2 Gen 1 Type A

1x fron 3.2 Gen1 Type C



Rear:

4x USB 3.2 Gen 1 Type A

2x USB 2.0
Front:

2x USB 3.2 Gen 1 Type A

1x fron 3.2 Gen1 Type C



Rear:

4x USB 3.2 Gen 1 Type A

2x USB 2.0
Front:

2x USB 3.2 Gen 1 Type A

1x fron 3.2 Gen1 Type C



Rear:

4x USB 3.2 Gen 1 Type A

2x USB 2.0
Front:

2x USB 3.2 Gen 1 Type A

1x fron 3.2 Gen1 Type C



Rear:

4x USB 3.2 Gen 1 Type A

2x USB 2.0
Front:
1x USB 3.2 Gen1 Type-C
2x USB 3.2 Gen1 Type-A
Rear:
1x USB 3.2 Gen1 Type-C
3x USB 3.2 Gen1 Type-A
2x USB 2.0
HDD/SSD 1TB 2.5" SATA SSD 1TB 2.5" SATA SSD 1TB 2.5" SATA 1TB SSD
512 GB SSD
1TB 2.5" SATA SSD + 1TB HDD
Peripherals MSI Gaming Mouse
MSI Gaming Keyboard
MSI Gaming Mouse
MSI Gaming Keyboard
MSI Gaming Mouse

MSI Gaming Keyboard
MSI Gaming Mouse

MSI Gaming Keyboard
MSI Gaming Mouse

MSI Gaming Keyboard
MSI Gaming Mouse

MSI Gaming Keyboard
Power Supply 500W 550W 550W 650W 500W 550W
Power Efficiency Level 80 Plus Bronze 80 Plus Gold 80 Plus Gold 80 Plus Gold - 80 Plus Bronze
Color Black Black Black Black Black Black
Dimensions 8.94" x 20.08" x 20.67" 8.94" x 20.08" x 20.67" 8.44" x 16.94" x 19" 16.94" x 8.44" x 19" 16.94" x 8.44" x 19" 8.46" x 16.93" x 17.72"
Weight 29.98 lbs 29.98 lbs 29.98 lbs 29.98 lbs 29.98 lbs 29.98 lbs
Warranty 1 Year 1 Year 1 Year 1 Year 1 Year 1 Year
