EVAPORATION PROOF TUBING

Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.

EXTENSIVE COMPATIBILITY

Stylish yet built for flexibility, the MAG CORELIQUID C240 EVA e-PROJECT has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.

  • Intel Socket
  • LGA 1150/1151/1155/1156/1200/1700
  • LGA 1366/2011/2011-3/2066
  • AMD Socket
  • AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

HIGH THERMAL DISSIPATION

A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.

LGA 1700 Compatible

The MAG CORELIQUID C240 EVA e-PROJECT liquid cooler provides out of box support for LGA 1700.

Pump Motor
Resonance Elimination

A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.

RADIATOR PUMP DESIGN

The pump has been integrated into the radiator for sound dampening and noise reduction. Additionally, placing the pump into the radiator also increases the pump's life expectancy by moving it away from the heat source.

Fan info

Number of Fans
2
Fan Dimensions
120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches
Fan Speed
500 ~ 2000 RPM
Fan Lighting
ARGB
Fan Air Flow
78.73 CFM
Fan Noise Level
14.3~34.3 dBA
Fan Air Pressure
2.39 mm-H2O
Fan Bearing
Two Ball Bearing
Fan Life Expectancy
70,000 hours
Fan Rated Current
0.15 A
Fan Power Consumption
1.8 W
PWM Mode
Yes
5V ARGB Cable Length
Socket: 550±10mm / 21.7±0.4 inches
PWM Cable Length
350±10 mm / 13.8±0.4 inches

Radiator Info

Radiator Material
Aluminum
Radiator Dimensions
276 x 120 x 27 mm / 10.87 x 4.7 x 1.06 inches
Water Cooling Pipe Length
400mm / 15.75 inches

Pump/Block Info

Block Dimensions
70.5 x 70.5 x 52mm / 2.78 x 2.78 x 2.05 inches
Block Lighting
ARGB
Pump Life Expectancy
100,000 hours
Pump Noise Level
18 dBA
Pump Load Current
0.34 A
Pump Power Consumption
4.08 W
Pump Speed
4200 RPM ± 10%
ARGB Cable Connector
Pin + Socket

Socket Info

Intel Socket
LGA 1150/1151/1155/1156/1200/1700
LGA 1366/2011/2011-3/2066
AMD Socket
AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

Accessories

1 to 2 Fan PWM Cable x 1
PSU Molex 4-Pin to 4-Pin(2 Pin Wired) Cable x 1
MAG-B660-TOMAHAWK-EVA-e-PROJECT MPG-GUNGNIR-110R-EVA-e-PROJECT

  • The MAG CORELIQUID C Series liquid cooler provides out of box support for LGA 1700.
  • The pump has been integrated into the radiator for sound dampening and noise reduction.
  • A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.
  • A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
  • Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.
