Marketing Name |
MS-6119
|
|
Model Name |
6119
|
|
PCB Version |
1/1.2
|
|
BIOS Version |
W6119IMS.210
W6119IMJ.290
|
|
CPU |
FSB
|
Ratio
|
Result
|
|
PII (Celeron) 233 |
66
|
3.5
|
OK
|
|
PII (Celeron) 266 |
66
|
4
|
OK
|
|
PII (Celeron) 300 |
66
|
4.5
|
OK
|
|
PII (Celeron) 300A |
66
|
4.5
|
OK
|
|
PII (Celeron) 333 |
66
|
5
|
OK
|
|
PII (Celeron) 366 |
66
|
5.5
|
OK
|
|
PII (Celeron) 400 |
66
|
6
|
OK
|
|
PII (Celeron) 433 |
66
|
6.5
|
OK
|
|
|
|
PII (Klamath) 233 |
66
|
3.5
|
OK
|
|
PII (Klamath) 266 |
66
|
4
|
OK
|
|
PII (Klamath) 300 |
66
|
4.5
|
OK
|
|
PII (Deschutes) 266 |
66
|
4
|
OK
|
|
PII (Deschutes) 300 |
66
|
4.5
|
OK
|
|
PII (Deschutes) 333 |
66
|
5
|
OK
|
|
PII (Deschutes) 350 |
100
|
3.5
|
OK
|
|
PII (Deschutes) 400 |
100
|
4
|
OK
|
|
PII (Deschutes) 450 |
100
|
4.5
|
OK
|
|
|
|
PIII (Katmai) 450 |
100
|
4.5
|
OK
|
|
PIII (Katmai) 500 |
100
|
5
|
OK
|
|
PIII (Katmai) 550 |
100
|
5.5
|
OK
|
|
PIII (Katmai) 600 |
100
|
6
|
OK
|
|
|
|
PIII (Coppermine) 500E |
100
|
5
|
OK
|
|
PIII (Coppermine) 550E |
100
|
5.5
|
OK
|
|
PIII (Coppermine) 600E |
100
|
6
|
OK
|
|
PIII (Coppermine) 650 |
100
|
6.5
|
OK
|
|
PIII (Coppermine) 700 |
100
|
7
|
OK
|
|
PIII (Coppermine) 800EB |
133
|
6
|
OK
|
|
PIII (Coppermine) 1G |
100
|
10
|
OK
|
Note: For Intel® Coppermine® CPU support, please check first if your motherboard have a blue sticker with the letter "C" located in the I/O chip, if yes, that means your system could support Intel® Coppermine® CPU. (The Winbond I/O chip is located near the Serial Port)
