Differences are marked in red WE63 8SJ-280 WE63 8SJ-235 WE63 8SJ-234 WE63 8SJ-233 WE63 8SI-238 WE63 8SI-239 WE63 8SJ-491

WE63 8SJ-235

WE63 8SJ-491

Manufacturer Part # WE63280 WE63235 WE63234 WE63233 WE63238 WE63239 WE63491
OS Windows 10 Pro Windows 10 Pro Windows 10 Pro Windows 10 Pro Windows 10 Pro Windows 10 Pro Windows 10 Pro
CPU Intel® Xeon® E-2176M Intel® Core™ i7-8750H Intel® Core™ i7-8750H Intel® Core™ i7-8750H Intel® Core™ i7-8750H Intel® Core™ i7-8750H Intel® Xeon® E-2176M
CPU Speed 2.7 - 4.4GHz 2.2 - 4.1GHz 2.2 - 4.1GHz 2.2 - 4.1GHz 2.2 - 4.1GHz 2.2 - 4.1GHz 2.7 - 4.4GHz
Chipset CM246 HM370 HM370 HM370 HM370 HM370 CM246
Color Aluminum Black Aluminum Black Aluminum Black Aluminum Black Aluminum Black Aluminum Black Aluminum Black
Screen Size 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare 15.6" FHD (1920*1080), wideview 94%NTSC color Anti-glare
Resolution 1920x1080 16:9 1920x1080 16:9 1920x1080 16:9 1920x1080 16:9 1920x1080 16:9 1920x1080 16:9 1920x1080 16:9
Visual Experience True Color Tech. True Color Tech. True Color Tech. True Color Tech. True Color Tech. True Color Tech. True Color Tech.
GPU NVIDIA Quadro® P2000 NVIDIA Quadro® P2000 NVIDIA Quadro® P2000 NVIDIA Quadro® P2000 NVIDIA Quadro® P1000 NVIDIA Quadro® P1000 NVIDIA Quadro® P2000
Video Memory 4GB DDR5 4GB DDR5 4GB DDR5 4GB DDR5 4GB DDR5 4GB DDR5 4GB GDDR5
Keyboard Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining Single white backlight with Anti-Ghost key+ silver lining
Speaker Speakers 3W*2 Speakers 3W*2 Speakers 3W*2 Speakers 3W*2 Speakers 3W*2 Speakers 3W*2 Speakers 3W*2
Memory 32GB (16G*2) ECC
DDR4 2133MHz
32GB (16G*2)
DDR4 2400MHz
16GB (16G*1)
DDR4 2400MHz
16GB (16G*1)
DDR4 2400MHz
16GB (16G*1)
DDR4 2400MHz
16GB (16G*1)
DDR4 2400MHz
32GB (16G*2) ECC
DDR4 2133MHz
HDD Capacity 512GB SSD(PCIE Gen3x4) 512GB SSD(PCIE Gen3x4) 512GB SSD(PCIE Gen3x4) 256GB SSD (PCIE Gen3x4) 512GB SSD(PCIE Gen3x4) 256GB SSD (PCIE Gen3x4) 512GB SSD (PCIE Gen3x4)
HDD Interface NVMe NVMe NVMe NVMe NVMe NVMe NVMe
LAN QCA8171 QCA8171 QCA8171 QCA8171 QCA8171 QCA8171 QCA8171
WLAN Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac) Intel 9560 Jefferson Peak (2x2 802.11 ac)
Bluetooth BT 5 BT 5 BT 5 BT 5 BT 5 BT 5 BT 5
Card Reader SD (XC/HC) SD (XC/HC) SD (XC/HC) SD (XC/HC) SD (XC/HC) SD (XC/HC) SD (XC/HC)
Webcam 720p HD Webcam 720p HD Webcam 720p HD Webcam 720p HD Webcam 720p HD Webcam 720p HD Webcam 720p HD Webcam
USB USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1 USB 3.1 Gen1 *2; USB 3.1 Gen2*1
Video Port HDMI *1, mDP*1 HDMI *1, mDP*1 HDMI *1, mDP*1 HDMI *1, mDP*1 HDMI *1, mDP*1 HDMI *1, mDP*1 HDMI *1, mDP*1
Audio Port Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1 Mic-in x 1, Headphone-out x 1
AC Power Adaptor 150W 150W 150W 150W 135W 135W 150W
Battery Pack 6 cell (51Whr) 6 cell (51Whr) 6 cell (51Whr) 6 cell (51Whr) 6 cell (51Whr) 6 cell (51Whr) 6 cell (51Whr)
Dimension 15.08"x10.24"x1.16" 15.08"x10.24"x1.16" 15.08"x10.24"x1.16" 15.08"x10.24"x1.16" 15.08"x10.24"x1.16" 15.08"x10.24"x1.16" 15.08"x10.24"x1.16"
Weight 5.05 lbs 5.05 lbs 5.05 lbs 5.05 lbs 5.05 lbs 5.05 lbs 5.05 lbs
Manufacturer Warranty 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global) 3 year Limited warranty (Include 1 Year Global)

WE63 8SJ-235

WE63 8SJ-491
